Sunday, July 22, 2018

Answer: How do you plot out data by region? The case of regional boundaries.


Our goal is to plot data by region..

.. an immensely handy thing to be able to do if you want to do basic analysis of geo-localized data.  For instance, here's a map of all the counties in the US, with color mapping out the median income for each county:

Figure 1. Median household income by county (2012). P/C Wikimedia.


Our Challenge for this week was to do something very similar--let me remind you of our Challenge:

1.  Can you make a map of the median household income for each of the MSAs in the United States?  (Or equivalent statistical areas, if you're from another country.)

As I pointed out, we can break down this problem into a few pieces:
1. Find a data set for the median household income that's organized by MSAs.
2. FInd a data set for the MSAs shapes.
3. Find a visualization application that can ingest both the median income data and the shape of the MSA and create a map similar to that above.
Here's what I did for each of the three steps.

1.  Find the data set.


My query to find the MSA income data:

     [ median income united states data 2017 intext:msa ]

This query led me fairly quickly to the FFIEC  data tables (Federal Financial Instutions Examination Council).
Remember that the intext:  operator requires that the term "MSA" be part of the document.  That's exactly what I needed to do in order to find this.
Figure 2. The data for median family income by MSA.

In particular, it wasn't hard to find that https://www.ffiec.gov/Medianincome.htm  had an Excel spreadsheet with median incomes where each row has the income and the code for one of the MSA regions.

This gives us the following spreadsheet (I downloaded the EXCEL file in row 1 above):

Figure 3.  The data table opened up to show the first 11 values of median income. Note the NSA/MD FIPS CODE NO.  (That's the code for the particular MSA region.)

 I opened this XLS, then deleted row 1 (to get rid of the not-very-useful heading information) and then deleted column C (to get rid of the data from 2015 that I don't want to show).

Then, I opened that Excel file in Fusion Tables because I happen to know that Fusion Tables has a way to import both Excel data files (like the one above) AND shape-files (like those that define the MSAs).

That Fusion Table now looks like this with just the GEOID (that is, the MSA number), the MSA area name, and the FFEIC estimated median family income (which is what we wanted to plot):

Figure 4.  The data from the XLS spreadsheet imported into a Fusion Table.



Now I need to find the MSA boundaries.  How can I do that?  Easy.  I did a search for KML files (which I know Fusion Tables can read) with this query:

     [ census metropolitan cartographic boundary KML files ]


On that page, I found the  Core Based Statistical Areas (CBSAs in KML format):  cb_2017_us_cbsa_500k.zip  This is a ZIP file (compressed), so you have to download it and decompress it, which gives you a bunch of   .KML  and .XML files.  Here, I'm just interested in the KML files.  They're the MSA "shapefiles," each of which outlines each of the MSAs.

Now I want to somehow grab all of these MSA shapes and line them up with each MSA median household data.  To do this, I'm going to import these shapes into a second Fusion Table, then merge the two tables together.  I'll make sure that both tables have rows that can line up and can be merged together because they have the same name and same values.

Here's how I did it:

We've already got one Fusion Table with all of the median incomes and a GEOID code telling us what MSA area that data represents.  Now, make a second Fusion Table to hold all of the KML regions, each of which has a code that's the same as the GEOID code.

Figure 5. The KML (shapefiles) for each of the MSAs in the US.

You can import the KML into it by just opening the KML file.  This should have a nice map with all 462 MSA regions on a map of the US.

Once you open the cb_2017_us_cbsa_500K.kml file in Fusion Tables, you should see this:

Figure 6: Fusion Table after I loaded the KML file with all of the MSA shapes.
This shows all of the MSA shapes in the KML file.  Notice anything odd?

If you click on the Rows1 tab, you'll see each row that defines one of those MSA shapes.  (The actual KML is in the far right-hand column.)

Figure 7.  The MSA Fusion Table with the GEOID in the 4th column,
 and the geometry of each MSA in the rightmost column


 Now, let's step back for a second.

We have 2 Fusion Tables.  One with the median income and an MSA region (both with the name and the GEOID for that region).  The other table has the KML shapes and a GEOID.

Now I want to MERGE the MSAs map shapes into the MSA income data where the rows have the same GEOID (that is, the same MSA region).

Notice that the column labeled GEOID has a unique identifier for each MSA region.  Notice that the Median income data table also has a column labeled “MSA/MD FIPS CODE NO.” – that’s the same thing.

Now, START with the Income Fusion Table.  Then select File>Find a Table to merge into this one.  The idea is that we'll pull in the MSA shapes (from the MSAs (2017) Fusion Table) and line up the matching rows with the same GEOIDs.

Figure 8.  How to merge the household income Fusion Table with another table.
(That is, to "fuse" them together.)


Select a table (with matching columns):

Figure 9.  Select the corresponding spreadsheet (in this case, the first one with the income data).


When you do this, it will align the rows with the same data in the GEOIDs field, and give you something like this.

Figure 10.  The default MSA median income data shown as a color of green.  (This is the default coloring pattern.)

There are a couple of problems with this map.

(1) The colors are all kind of the same.  The default color scheme is a gradient of greens, but that doesn't quite distinguish the different values very well.  We can fix this by changing the colors assigned to each income range.  To do this, you have to edit the colors assigned to each income range.  To do this, you have to change the settings for the "map feature style"


Figure 11.  How to change the polygon fill pattern to show
different income ranges as differing colors.


What you'll want to do is to change the range / color assignment.  To do this, just click on the "Buckets" tab.  That menu looks like this:


Figure 11.  Changing the buckets and the corresponding colors.

This menu option lets you change the bucket sizes (and notice that you have to scroll to get to all of the buckets).  For each bucket, you can pick your own colors.  Here's another version of the median income map.  You can easily change the colors to emphasize (or de-emphasize) whatever data features you'd like.

Figure 12.  The new MSA map with a somewhat better color choice.


However...

(2) The biggest surprise to me was how many MSAs seem to be missing, including some close to where I live.  (See the map below...)  In particular, how is it possible that the greater San Francisco area is missing?


Figure 13.  A closeup of the map.  Some MSA regions seem to be missing!

What happened to San Francisco??

There's some kind of missing data.  This was so striking, I had to check.

First, look up above at the map that shows all of the MSAs ("MSAs (2017)" with all of the red blobs).  There are a LOT of open spaces in the map.  Surprise!  The MSAs do not cover the entire United States.  I didn't realize this when we started this Challenge, but the MSAs are an incomplete cover of the US landscape.  That's observation 1.


Second, it looks like some MSAs are just plain missing in the original spreadsheets.  (See Figures 3 and 4.  We can see that the MSA region is in the dataset for San Francisco, but when we look in the median income database, we see it's in there.

I puzzled over this for a long time (like... 4 hours!) before I figured out what happened.  The GEOID code for the San Francisco MSA was wrong in the map file.  I noticed this because I finally pulled out the records for both the MSA spreadsheet and the one line of the MSAs Regions KML file.  In the "median income" file, the GEOID was 41884, while in the "KML regions" file, the code was 42034!

Basically, a Fusion Table takes two (or more) data tables that have a column in common.  In this case, I used the GEOID code to line up the data sets.  As you saw, it worked pretty well.

But if a code is wrong (as it was in the MSA KML mapping file), then only half of the data transfers--in this case, the KML region doesn't get copied over.  Damn.  THAT took a while!

To fix it, I just opened the "incomes" spreadsheet, and fixed the GEOID number so it would line up with the KML regions file.  And, voila!  The closeup of the San Francisco region now looks like this (notice that I changed the colors once again... I was experimenting with different settings):


And yes, the Median Family Income for the Bay Area in 2017 was $113,100 / year.

Naturally, after I did all this, as I was cleaning up my tabs I found a really great example (with videos!) on how to do this.  If you're interested in this kind of data understanding, check out Ken Blake's instructional web page and videos.   (It's really done quite well.)


SearchResearch Lessons

Well, we didn't get a lot of comments this past week.  I don't know if it's the summer slump, or if people just didn't find this kind of demographic analysis interesting!  (Let me know in the comments.  If nobody speaks up, I won't do many of these in the future.)

There were a couple of things to take away from this lesson:

1.  You have to know what your tools can do.  In this case, I had a headstart because I knew that Fusion Tables could do something close to this (especially the mapping part).  Of course, one of the SRS skills is toolfinding.  (When you find yourself trying to do something complicated, check for a tool that can help you out.)

2. Remember how to use intext: to require that a particular key search term is on the page.  When you really need that term to be there, intext: can really, really help.

3.  Not all data sets are error free!  Yes, I know this data set came from the government... but they have typos too.  And remember that as data sets grow larger, it gets increasingly difficult to spot typo-type errors.  An excellent practice is to spot check a number of different locations (and to check with a filter, if you can).  I ended up finding several more coding errors in that data set.


Postscript:  Sorry that this week's SRS post was a little delayed.  I was traveling to a wonderful event--the Salzburg Global Seminar--and was busy giving talks, and talking with a bunch of very smart and completely fascinating people.  I'm actually flying on Wednesday, but will try to post the Challenge before we lift off.  (But if I don't get it out, you'll know what happened.)



Wednesday, July 11, 2018

SearchResearch Challenge (6/11/18): How do you plot out data by region? The case of regional boundaries.


It's time for a Challenging Challenge!

As you know, every so often I like to mix up the SRS Challenge with something that's a bit more in-depth.  (And if this is overwhelming, just take the week off--I'll be back next week with an easier one.)

The Setup:  If you read the news these days you'll see all kinds of claims about various kinds of data.  In an earlier SRS post we talked about immigration rates, and found that the data is a bit complicated, but you can figure it out.

One of the things you'll see in the news are charts like this one:

.. by COUNTY (not MSA or CSA).

This is the "Median household income in 2012 by county."  This chart is from Wikimedia and shows the median income by county in the US.  Of course, counties are sometimes just arbitrary boundaries.  They may or may-not make sense.  (For instance, Los Angeles County has around 10M souls living inside the county, while only 600K people live in Providence county, Rhode Island.  That's a factor of 16X difference in size.)

There are many ways to draw regional boundaries that make some kind of sense. For instance, gerrymandering is the practice of drawing political boundaries to give a particular party more (or less) voting power.

There are commercial regional boundaries (such as the "Designated Market Areas," aka DMAs, define by the polling / survey company Nielsen).  These regions correspond to media markets.
More often, though, people who are looking at data use either "Metropolitan Statistical Areas" (MSA).  An MSA is “is a geographical region with a relatively high population density at its core and close economic ties throughout the area.”
For instance, the San Francisco-Oakland-Hayward Metropolitan Statistical Area (with a population of 4.5 million) and the larger San Jose-San Francisco-Oakland Combined Statistical Area (8.4 million) are both near where I live in Silicon Valley.
A slightly different version of the MSA is the "Combined Statistical Area" (CSA), whi is composed of "adjacent metropolitan (MSA) and micropolitan (μSA) regions in the United States and Puerto Rico that can demonstrate economic or social linkage."  (This is primarily defined by commuting patterns.)
A map of the combined metropolitan and micropolitan statistical areas of the US looks like this:
Wikimedia

I'm telling you all of this background because it leads to today's Challenge.
1.  Can you make a map of the median household income for each of the MSAs in the United States?  (Or equivalent statistical areas, if you're from another country.)
That is, you'll need to:
A. Find a source of recent data that's organized by MSAs.  2017 would be best, but you should look for the most recent data.
B. Find a visualization application that can ingest both the median income data and the shape of the MSA.
C. Figure out a way to create a visualization of the US MSAs that color-codes the income.  It should look a bit like the above example, except with the income level determining the color of the MSA region.
This is a bit of a Challenge, but it doesn't require programming.  (If you want to program, be my guest, but this doesn't really need it.)
And, if you really don't like MSAs as the boundaries of map regions... find a different one, and tell us why you like yours better.
Once you figure out how to do this, you'll have the means to do your own analysis, looking at data in your own way.
Search on!


P.S. This is the kind of thing that Data Scientists do all the time.  With this Challenge, I'm hoping to instill some of the skills and values that Data Scientists bring to the job every day.  Hope you have fun with it.  I'm looking forward to your comments!





Wednesday, July 4, 2018

Answer: How big was the range of these animals?


What's the original / natural range?

The basic question from last week's Challenge was "What was the original or natural range of these three animals?"  (Lion, Ground Sloth, Camel)  It's a natural enough question, but the answers can be surprising.




The Challenge was:


If there were, once upon a time, lions and camels and ground sloths  (Oh my!) in North America, what was their historic region?  During the past 100,000 years, where could you find camels, lions, and ground sloths?

Basically what we're looking for is a map of  the ranges of these animals.  But... it's tricky.  The obvious queries like:
     [ historic range lion ]
can give us conflicting answers.  What's going on here?

With questions like this, we need to be very clear about what our terms actually mean.  It sounds obvious, but what, really, is a lion?

For instance, it's easy to find this map from the above query on Wikipedia:

"Historic lion range" per Wikipedia

But the number of variant answers that we see tell us that the problem is a little subtle:

What do you mean by "lion" and what do you mean by "historic"?

Reading the Wikipedia article about lions we find:  "In the Pleistocene, the lion ranged throughout Eurasia, Africa and North America from the Yukon to Peru.."  Really?  There were lions in North America?

We must go deeper.

And it doesn't take us long to learn that there are extinct subspecies of lions, and that today the American lion that lived during the Pleistocene is usually treated as a sub species of the African lion‭ (‬Panthera leo‭), ‬which is why it is more commonly listed as Panthera leo atrox.‭ ‬However there are a number of researchers who consider the American lion to be different enough from the African lion to give it its own distinct species of Panthera atrox.

But this is just the tip of the iceberg when dealing with the classification of the American lion and it‭’‬s easy to become lost in all of the multitude of theories and arguments about its true position in the Panthera clan.

Of course, there's another lion that's known from its bones, the Eurasian cave lion‭ (‬Panthera leo spelaea‭), ‬which is itself another kind of closely related lion that went extinct about 13,000 years ago.  ‬This similarity has been confirmed by mitochondrial DNA analysis which shows that the American lion and Eurasian cave lion were almost identical,‭ ‬although the American does seem to have grown slightly larger.‭‭  (See the Wikipedia article about leo spelaea.)

So if we look for range maps for each of these subspecies of lion (notice how I'm looking for this particular species name, not just for lion):

     [ map range Panthera leo spelaea ]

we'll see a number of maps, such as this one:


Historic range (13,000 years ago) of Panthera leo spelaea  (From a paper on its genetics)

Although even this map seems a little incomplete--as we see in the Encyclopedia of Life entry about the American Lion, its range went down into northwestern South America.   (Another article about lions in South America.)  It never lived in Australia or Antartica, but something very much like a lion seems to have lived just about everywhere else.

So... what's its original range?  Well, there were lions just about everywhere--in North and South America, as well as all of Africa, most of Europe, and vast swaths of Asia.


What about the ground sloth?  We don't see them roaming around anywhere these days.  So what was their original range?

Let's go back to our previous question:  What do you mean by ground sloth?



The Wikipedia article on ground sloths seems fairly complete.  It tells us that (summarizing here):

Ground sloths are a diverse group of extinct sloths in the mammalian superorder Xenarthra.... a term used as a reference for all extinct sloths because of the large size of the earliest forms discovered, as opposed to existing tree sloths...
Much ground sloth evolution took place during the late Paleogene and Neogene of South America while the continent was isolated. At their earliest appearance in the fossil record, the ground sloths were already distinct at the family level. The presence of intervening islands between the American continents in the Miocene allowed a dispersal of forms into North America. A number of mid- to small-sized forms are believed to have previously dispersed to the Antilles. They were hardy as evidenced by their diverse numbers and dispersals into remote areas given the finding of their remains in Patagonia (Cueva del Milodón) and parts of Alaska.
Sloths, and xenarthrans as a whole, represent one of the more successful South American groups during the Great American Interchange. During the interchange, many more taxa moved from North America into South America than in the other direction. At least five genera of ground sloths have been identified in North American fossils; these are examples of successful immigration to the north.

(And, yes, I checked other resources about camels, e.g., books about camel evolution.  This story checks out.)

Reading through this, we see that ground sloths (the Xenarthrans) inhabited at least North and South America, from Patagonia to Alaska... AND much of the Caribbean!  That's a huge range.  Some varieties were just gigantic--five tons in weight, 6 meters (18 feet) in length, and able to reach as high as 17 feet (5.2 m).  These were significant megafauna of the American landscape.

One particular kind of ground sloth has a special place in American history (which we're celebrating today, July 4th).  The megaloynx ground sloth was first identified by Thomas Jefferson in a paper that he presented before the American Philosophical Society on March 10, 1797: "A Memoir on the Discovery of Certain Bones of a Quadruped of the Clawed Kind in the Western Parts of Virginia."



This paper is widely seen as establishing the science of vertebrate paleontology in the US.  Interestingly, Jefferson identified the Megalonyx as a giant lion, and asked Lewis & Clark to be on the lookout for any Megalonyx as they explored the American west in their expedition of 1804 - 1806.  Jefferson, along with many other scientists of the time, had no idea that animals could go extinct, and so he naturally saw these bones in terms of existing animal forms.  Alas, he missed the last Megalonyx by a few million years.

But their range was clear:  It varied by species, but collectively, the ground sloths were found in the Americas.


Finally, what about camels?

Again I have to ask:  What do you mean by camels?

If  we check the Wikipedia page on camels, we learn that dromedaries live in the Middle East and the Horn of Africa, while Bactrian camels are native to Central Asia, but live throughout remote areas of northwest China and Mongolia.  (Historically, the area known as Bactria is the flat region straddling modern-day Afghanistan, Tajikistan, and Uzbekistan. More generally, Bactria was the area north of the Hindu Kush, west of the Pamirs and south of the Tian Shan with the Amu Darya flowing west through the center.)

But we also learn that an extinct species of camel in the separate genus Camelops, known as C. hesternus, lived in western North America before humans entered the continent at the end of the Pleistocene.

This takes us, once again, into a definitional moment.

Looking up the evolution of camels, we learn that the earliest known camel, called Protylopus, lived in North America 40 to 50 million years ago.  It was about the size of a rabbit and lived in the open woodlands of what is now South Dakota. 35 million years later, the Poebrotherium was the size of a goat and had many more traits similar to camels and llamas.

But the direct ancestor of all modern camels, Procamelus, lived in North America around 3–5 million years ago.  This proto-camel species, Camelidaespread to South America as part of the Great American Interchange,  where they gave rise to guanacos and related animals.  They also spread to Asia via the Bering land bridge, including Ellesmere Island (in modern Canada, well above the Arctic Circle, near Greenland).

Procamelus from the mid-Miocene in Colorado, by Robert Horsfall.
 (p/c: Wikimedia, from the book
  A history of land mammals in the western hemisphere by William Berryman Scott)



The Wikipedia article on camels tells us that the "last camel native to North America was Camelops hesternus, which vanished along with horses, short-faced bears, mammoths and mastodons, ground sloths, sabertooth cats, and many other megafauna, coinciding with the migration of humans from Asia."

Well, that's interesting:  the American Lion, ground sloths, and camels all went extinct around the time humans appeared in the Americas.

So if we consider as camels only "large animals with humps"  (and not the smaller camelids like llamas and guanacos), their range was historically North America, then spreading into central Asia and the Middle East.

If you search for other possibilities (e.g., [ Europe camel] or [Africa camel]) all you'll find are references to the (relatively recent)  introduction of camels into those places.

Likewise, camels seem to have spread a bit more recently into places you might not have expected.

Around 700,000 dromedary camels are now feral in Australia, descended from those introduced as a method of transport in the 19th and early 20th centuries.  This population is growing about 8% per year, even becoming a problem as they consume resources in a limited landscape.


In North America, after being away for a 15,000 years, a small population of introduced camels were imported in the 19th century as part of the U.S. Camel Corps experiment. Never a full part of the Army, it was a short-lived experiment to use camels in arid climes instead of horses. When the project ended a few years later, they were sold to be used as draft animals in mines, some escaped, or were released in to the desert. Twenty-five U.S. camels were bought and imported to Canada during the Cariboo Gold Rush.  (NYTimes article about the Camel Corps.)

Upon finding water during a surveying trip, horses would drink immediately, while the accompanying camels would show little interest (see the camels in the upper right background). The Army’s camels proved they could withstand the oppressive climate of the American Southwest and other hardships that could send horses and mules into a panic. (Horses Quenching Their Thirst, Camels Disdaining, by Ernest Etienne de Franchville Narjot, courtesy of The Stephen Decatur House Museum)


Search Lessons


There are two big lessons here (and one little one).

1.  Be clear about what you're searching for!  In the case of the lion, do you mean to include American Lions?  Or only the African variety?  In our case, we chose to go with clearly related (albeit extinct) lions (e.g., the Cave lion and the American lion).  This changes your search strategy to include very specific terms, like Panthera leo spelaea, or Pathera atrox.  Likewise, we had to make a cutoff for camels since the evolutionary slope is a bit slippery.  We didn't want to include camelids like llamas, so we went with "big cloven footed animalas with humps" which evolved at a particular time.  (Note:  camels and llamas can interbreed, although like mules, the offspring is sterile... so we chose a morphological cut-point, rather than a clear species boundary.)

2.  Checking Images is sometimes helpful for finding maps that give extents.  As a general strategy, I often check Google images for information that's presented graphically, using the same queries as I use when searching the web.  About half the time, I end up learning something that I hadn't anticipated learning.  Serendipity is your friend, and Image search lets serendipity happen!

3.  (A small point)  I found the image of the Procamelus not by doing "regular" web search, but by searching on Wikimedia.  Normally, I think of Wikimedia as being the repository for all of the images on Wikipedia, but sometimes you can find images that appear only in the Wikimedia collection that don't seem to appear anywhere else in Wikipedia.  This is incredibly handy for teachers (and blog post writers) because they come with the copyright information and are often uncommon images.  It's easy to search this space, just use a site: query like this:  [ site:wikimedia.org procamelus ] You'll find all of the images you might need, along with useful copyright information.


Ending note:
This week's post took longer than normal for a couple of reasons--the book needed attention, I had a few things to do at work, and there was a bug in Blogger than I needed to run down.  (One of the downsides of working at Google is that I feel obligated to help find bugs in our products. C'est la vie.)
As I was feeling bad about being slow to stick to the publication cycle, I realized that the rest of the summer is going to be busy as well.  I'm teaching a few search classes in Europe, and taking a bit of vacation in places that won't have Wifi, nor will I have my computer.  These places should be fun, and should lead to even more interesting SearchResearch Challenges.
I'll keep writing, and will write something every week (unless I know I'm going to be off the grid, but I'll give a heads-up when I know...).

Until then, Search on!
